Hardened M12 Industrial Gigabit PoE+ Injector Waterproof IP68 Interface 12-48VDC Input Support The PoE IEEE 802.3 af/at 30W Power Sourcing Equipment
Hardened M12 Industrial Gigabit PoE+ Injector Waterproof IP68 Interface 12-48VDC Input Support The PoE IEEE 802.3 af/at 30W Power Sourcing Equipment
Overview
EN50155 compliant PoE Injectors are designed for industrial applications, such as rolling stock, vehicle,
and railway applications. The PoE Injector is an advanced IEEE802.3at compliant device with Intelligent Detection
that provides 1-port 10/100/1000 Base-T(X) PoE output which is compliant with EN50155. It is specifically
designed for the toughest industrial environments. The EN50155 PoE Injector uses M12 connectors to ensure
tight, robust connections, and guarantee reliable operation during environmental disturbances, such as vibration
and shock. The device does not turn on power until it detects a valid PoE signature from the PoE devices attached
downstream in the network. This provides protection against damage to non-PoE compliant devices which may be
connected to the Ethernet cable.
LNK-INJ301-M12 provides an integrated power solution with a wide range voltage of 12~48VDC for high
availability applications.
Features:
► 12~48VDC Power Input
► Fully compliant with IEEE802.3af/at
► Support 10/100/1000Base-TX for power and
data output
► Support DIN-Rail & Wall-mount installation
► Use M12 connectors to ensure tight and robust
connections
► Extensive LED indicators for PoE diagnostics
► Environmentally Hardened -40 ° C to 80 ° C
(-40 ° F to 176 ° F) operating temperature
Materials
Materials
Aluminum
