8 Outlets Switched PDU Surge Protection Power Strip with High-Precision Measuring Instruments 1U 19" Rack Mount Metered Power Distribution Unit 100-250V 16A
8 Outlets Switched PDU Surge Protection Power Strip with High-Precision Measuring Instruments 1U 19" Rack Mount Metered Power Distribution Unit 100-250V 16A
Couldn't load pickup availability
Hereta's Electric Basic Rack Power Distribution Units (PDUs) Metered .distributes power to devices in the19’’ rack. The PDUs with 8 outlets and one surge protector. Universal 10/16A 100–240V PDU is compatible with wide range of voltages to deliver single-phase AC power to multiple loads from a utility outlet, generator or UPS system. Ideal for data centers, server rooms and network wiring closets.
The reversible all-metal housing supports a variety of mounting options, including 1U horizontal or 0U vertical
mounting in EIA-standard 19-inch racks, under a counter or on a wall or workbench
Features:
- 100–240V AC input, 8 total outlets
- Max 16A / 2800W Output
- Metered PDU
- Measurement Accuracy:Grade 1
- Display OLED Screen
- Support 19 inch Rack-mount
- Gen 3 Replaceable Surge Protection module
- L and N Double-break Switch
- UL94V-0 Grade Flame Resistant Material
- Four-layer Piano Paint T6 Hardened Aluminum Profile
- Complies with the requirements of IEC60297 standards;
- RFI Protection
ENVIRONMENTAL:
Operating Temperature:-10 to 50°C
Storage Temperature:-30 to 60°C
Relative Humidity:5 to 95% non-condensing
Operating Elevation:0-4000m
Warranty Period:3-years limited warranty
